#Smart tool sensor module Bluetooth#
This IoT module integrates the A111 Pulsed Coherent Radar and the Nordic nRF52840 System on Chip that supports a 32-bit 64 MHz ARM® Cortex™-M4 CPU with 256 KB SRAM and 1 MB Flash including support for Bluetooth 5, Bluetooth mesh, Thread, Zigbee, 802.15.4 and ANT. The XM122 IoT Module from Acconeer is a low power connected radar module with optimized circular form factor with a diameter of 33mm. An exploration Tool which helps visualize the radar measurement results can also be downloaded at Acconeer Github.
#Smart tool sensor module software#
The Acconeer RSS including a Software Development Kit (SDK) for stand-alone usage is available for download to the XM132 via the Acconeer developer page. It can also be used with an external host controller where communication to the module is through a register command protocol using one of the following interfaces: UART, I2C, GPIO. The XM132 can be used as a stand-alone module where customers can embed their application on top of the Acconeer RSS (Radar System Software) using the RSS API (Application Programming Interface). With software adapted for specific use cases, cost and time-to-market is streamlined. The XM132 Entry Module is an integration-ready module intended to be used for evaluation and development purposes as well as for integration into commercial products. The module supports a single supply operating voltage range from 1.8V to 3.6V. This Entry module integrates the A111 Pulsed Coherent Radar with a 32-bit 64MHz Arm Cortex M0+ MCU, the STM32G071CBU6 from STMicroelectronics with 128 Kbytes of Flash memory and 36 Kbytes of RAM memory. The XM132 eNTRY Module from Acconeer is an integration-ready radar module with optimized for selected use cases. The unique characteristics of the A1 radar sensor make it possible to identify materials and detect motion in advanced sensor applications. The A1 radar sensor can detect multiple objects at close range with single measurements as well as continuous sweeps set to any frequency up to 1500 Hz. Radio technology makes the sensor easy to integrate without the need for an aperture. By operating in the 60 GHz unlicensed ISM radio band, the radar sensor provides robust performance without interference from noise, dust, color nor direct or indirect light. The A1 radar sensor is based on a unique patented technology enabling millimeter accuracy with very low power consumption. The small size and low power consumption are ideal for integration into compact battery-driven and mobile devices.
The A1 radar sensor is delivered as a one chip system in package (SiP) solution with embedded radio and antenna. The A1 radar sensor is a low power, high precision, pulsed short-range radar sensor with a footprint of only 29 mm2.
